MEMS Gas Sensors
MSGS-O2 zirconia oxygen sensors

Applications: Ventilator, oxygen chamber, incubator, oxygen collector, inert gas treatment, fermentation equipment, food detection, monitoring outdated growth, wine cellar gas storage, refinery diving.

Features

  • Zirconia sensitive test unit

  • Long service life, non-consumable testing technology

  • No need for reference gases

  • A varity of output siginal types are optional

  • High measurment accuracy

  • Internal integrated heating

  • Immediate calibration in the air

  • No need for stable external ambient temperature


Main Applications

Ventilator, oxygen chamber, incubator, oxygen collector, inert gas treatment, fermentation equipment, food detection, monitoring outdated growth, wine cellar gas storage, refinery diving.


Specifications

Heater voltage

Standard sensor

4VDC±0.1VDC

fast response sensor

4.35VDC±0.1VDC

test wait mode

2VDC±0.1VDC

@700 Oxygen pump impedance

<6kΩ

Operating temperature

-100~250

Oxygen pressure monitoring range

2mBar~3Bar

Test accuracy (oxygen partial pressure)

5mBar

Response time (T90)

Standard sensor

<15s

Fast response sensor

<4s

Start-up time

Cold start time

60s

Wait mode start

20s

Test stability time

180s

Weight

Standard sensor

7g

Fast response sensor

9g

Detection velocity range

1~10m/s
